Eaton Standard Ce Approved 90 Elbow Tube Fitting Bc. Bd Bc-Rn, Bd-Rn

Name: Eaton Standard Ce Approved 90 Elbow Tube Fitting Bc. Bd Bc-Rn, Bd-Rn
Rating: 5 (99 reviews)

Product Description
hydraulic adaptor metric male O-Ring flat sealing pipe fittings

Material: Carbon Steel, Stainless Steel
Surface Treatment: White or Yellow Zinc-Plated
Standards: Eaton, DIN, ISO, SAE, JIC or As customers' drawing
Export Markets: Global

Get A Quote

سابقV：Hydraulic Pipe Fittings / 4c / 4D / Metric Male Thread Hydraulic Plug
لاحق：Reducer Tube Adaptor with Swivel Nut

Specification
Contact Us

Standard:	DIN
Material:	Medium Carbon Steel
Connection:	Female
Surface Treatment:	Galvanized Sheet
Head Type:	Round
Manufacturer:	Factory

PART NO.	THREAD E,G	THREAD F	TUBE O.D. D1,D3	TUBE O.D. D2	DIMENSIONS I1,I3	DIMENSIONS L1,L3	DIMENSIONS L2	DIMENSIONS S1	DIMENSIONS S2,S4	DIMENSIONS S3	MPa
PART NO.	THREAD E,G	THREAD F	TUBE O.D. D1,D3	TUBE O.D. D2	DIMENSIONS I1,I3	DIMENSIONS L1,L3	DIMENSIONS L2	DIMENSIONS S1	DIMENSIONS S2,S4	DIMENSIONS S3	MPa
BC-12	M12×1.5	M12×1.5	6	6	12	27	26	12	14	14	31.5L
BC-14	M14×1.5	M14×1.5	8	8	14	29	27.5	12	17	17
BC-16	M16×1.5	M16×1.5	10	10	15	30	29	14	19	19
BC-18	M18×1.5	M18×1.5	12	12	17	32	29.5	17	22	22
BC-22	M22×1.5	M22×1.5	15	15	21	36	32.5	19	27	27
BC-26	M26×1.5	M26×1.5	18	18	23.5	40	35.5	24	32	32
BC-30	M30×2	M30×2	22	22	27.5	44	38.5	27	36	36	16L
BC-36	M36×2	M36×2	28	28	30.5	47	41.5	36	41	41
BC-45	M45×2	M45×2	35	35	34.5	56	51	41	50	50
BC-52	M52×2	M52×2	42	42	40	63	56	50	60	60
BD-14	M14×1.5	M14×1.5	6	6	16	31	27	12	17	17	63S
BD-16	M16×1.5	M16×1.5	8	8	17	32	27.5	14	19	19
BD-18	M18×1.5	M18×1.5	10	10	17.5	34	30	17	22	22
BD-20	M20×1.5	M20×1.5	12	12	21.5	38	31	17	24	24
BD-22	M22×1.5	M22×1.5	14	14	22	40	35	19	27	27
BD-24	M24×1.5	M24×1.5	16	16	24.5	43	36.5	24	30	30	40S
BD-30	M30×2	M30×2	20	20	26.5	48	44.5	27	36	36
BD-36	M36×2	M36×2	25	25	30	54	50	36	46	46
BD-42	M42×2	M42×2	30	30	35.5	62	55	41	50	50
BD-52	M52×2	M52×2	38	38	41	72	63	50	60	60	31.5S
"RN", BC-30RN. Note: In case if you are interested to order the adapter in complete set with cutting ring and nut, it is necessary to insert suffix "RN" after our part NO.,for example BC-30RN

About OPK Fitting

OPK FITTING Hydraulic Equipment Factory is a specialized domestic factory with hydraulic pipes and adaptors production experience. Our managing scope relates to various fields such as hydraulic systems etc.; Including all kinds of materials with different pressure levels, flexible hydraulic hoses with various size criteria, hose fitting, adaptor, etc. They have been respectively applied in the hydraulic and fluid conveyance systems of industries, such as machinery, metallurgy petroleum, construction, ships, space-flight, agriculture, pharmaceutical, food, and so forth.
Ningbo OPK Fitting Co., Ltd. is a China professional Eaton Standard Ce Approved 90 Elbow Tube Fitting Bc. Bd Bc-Rn, Bd-Rn manufacturers and ODM & OEM Eaton Standard Ce Approved 90 Elbow Tube Fitting Bc. Bd Bc-Rn, Bd-Rn factory .We can provide custom-made stainless steel hydraulic fittings, hydraulic hose crimp fittings, and hydraulic quick couplings.

Over 10 years of experience.

A team of skilled design professionals and talent.

Excellent product quality and thoughtful customer service.

Our 10 years of customisation experience has created the OPK Fitting brand value.
